WL_ReadyLamp

This indicator illuminates:

When the vehicle is ready to be driven.

• ON: Normal driving is possible.

• OFF: Normal driving is not possible, or a problem has occurred.

When the READY indicator goes off or blinks, there is a problem with the system. If this occurs, we recommend that your vehicle be inspected by an authorised HYUNDAI dealer.

WL_ServiceWarningLamp

This warning light illuminates:

• When you set the Engine Start/Stop button to the ON position.

  • The service warning light illuminates for about 3 seconds and then turns off when all checks have been performed.

• When there is a problem with the hybrid vehicle control system or hardware.

When the warning light illuminates whilst driving, or does not go OFF after starting the vehicle, we recommend that your vehicle be inspected by an authorised HYUNDAI dealer.

WL_EVLamp

This indicator illuminates:

When the vehicle is driven by the electric motor.

WL_RegeneratingLamp

This warning light illuminates:

When the regenerative brake does not operate and the brake does not perform well. This causes the Brake Warning light (red) and Regenerative Brake Warning Light (yellow) to illuminate simultaneously.

If this occurs, we recommend that your vehicle be inspected by an authorised HYUNDAI dealer. The operation of the brake pedal may be more difficult than normal and the braking distance may increase.
