Rear Combination Light Replacement

2C_RearLampOverview

  1. Stop light
  2. Tail/Stop light
  3. Turn signal light (Type A: Bulb, Type B: LED (if equipped))
  4. Backup light (Type A: Bulb, Type B: LED (if equipped))
  5. Garnish tail (if equipped)
  6. Rear side marker

If the LED light does not operate, contact an authorized HYUNDAI dealer for replacement.

The LED light cannot be replaced as a single unit. A skilled technician should check or repair the LED light, for it may damage related parts of the vehicle.

Turn signal light, Backup light (bulb type)

  1. Disconnect the negative battery cable.

  2. Loosen the retaining clips under the bumper and screws on the wheel house trim.

  3. Pry trim under the bumper toward the vehicle.

  4. Remove the socket from the assembly by turning the socket counterclockwise until the tabs on the socket align with the slots on the assembly.

  5. Remove the bulb by pulling it straight out.

  6. Insert a new bulb in the socket.

  7. Reinstall the light assembly to the body of the vehicle.

  • Wear eye protection when changing a bulb. Allow the bulb to cool down before handling it.

  • Always handle them carefully, and avoid scratches and abrasions. If the bulbs are lit, avoid contact with liquids.

  • Never touch the glass with bare hands. Residual oil may cause the bulb to overheat and burst when lit.

  • A bulb should be operated only when installed in a turn signal light.

  • If a bulb becomes damaged or cracked, replace it immediately and carefully dispose of it.

  • Replacing the bulb may cause damage to the bulb relevant parts of the vehicle, and also may cause injuries. To replace the turn signal light, visit an authorized HYUNDAI dealer.
