Driver assistance system sensors

The Driver Assistance system on your vehicle uses cameras and sensors to help detect potential hazards in the vicinity of your vehicle.

2C_ADASSensor

2C_ADASSensor_1

  1. Front view camera
  2. Front radar
  3. Front corner radar
  4. Front ultrasonic sensors
  5. Front side ultrasonic sensors
  6. Wide-front/side/rear view camera
  7. Rear corner radar
  8. Rear side ultrasonic sensors
  9. Rear ultrasonic sensors

To prevent serious injury or death:

  • Never disassemble the sensors or sensor assemblies, and never apply any impact on it.

  • Only have the detecting sensor replaced or repaired by an authorized HYUNDAI dealer.

  • Never install any accessories, stickers, or tint the front windshield.

  • Always keep the camera dry.

  • Never place any reflective objects (e.g. white paper, mirror) on the dashboard.

  • Do not use any cleanser containing acid or alkaline detergents when cleaning the camera lenses. Use only a mild soap or neutral detergent, and rinse thoroughly with water.

  • If there is impact on or near the sensor, the sensors may be damaged or not be properly aligned near the radar, even though a warning message does not appear on the instrument cluster, Driver Assistance system may not operate properly. Have the vehicle inspected by an authorized HYUNDAI dealer.

  • Do not install a license plate frame or other objects such as bumper sticker, film, bumper guard, or bumper wrap near the radar.

  • Driver Assistance system may not work properly if the bumper has been replaced, or the surroundings of the radar has been damaged or painted.

  • If a trailer or hitch mounted carrier is attached, it may adversely affect the performance of the rear corner radar or Driver Assistance system may not operate.

  • Always keep the ultrasonic sensors clean.

  • Do not spray the ultrasonic sensors or the surrounding area directly with high pressure water.

  • Do not apply objects such as bumper sticker or bumper guard, near the ultrasonic sensors or never apply paint to the bumper or other locations.

  • Never disassemble or strike the ultrasonic sensors components.

  • Do not modify the vehicle bumper height or ultrasonic sensor installations. Any non-factory installed equipment or accessories may also interfere with the sensor performance.

  • If the ultrasonic sensors have been forcibly moved out of proper alignment or are damaged, have the vehicle inspected by an authorized HYUNDAI dealer.
