Recommended lubricants and capacities
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy.
We recommend that the system be checked by an authorized HYUNDAI dealer.
|
Lubricant |
Volume |
Classification |
||
|
Engine oil *1 (drain and refill) Recommends
|
Smartstream G2.0 |
4.3 ℓ (4.54 US qt.) |
Except Middle East*3 |
0W-20 API SN PLUS/SP or ILSAC GF-6 *1 |
|
For Middle East*3 |
5W-30(ACEA A5/B5) or 0W-30(API SN PLUS/SP or ILSAC GF-6) *1 |
|||
|
Smartstream G1.6 |
3.8 ℓ (4.02 US qt.) |
Except Middle East*3 |
SAE 0W-20, API SN PLUS/SP or ILSAC GF-6*2 |
|
|
For Middle East*3 |
SAE 5W-30, ACEA A5/B5*7 |
|||
|
Smartstream G1.6 T-GDI |
4.8 ℓ (5.07 US qt.) |
Except Middle East*3 |
SAE 0W-20 API SN PLUS/SP or ILSAC GF-6*2 |
|
|
For Middle East*3 |
SAE 5W-30 / ACEA A5/B5*7 |
|||
|
1.6 D-CVVT |
3.6 ℓ (3.80 US qt.) |
Except Middle East, India*3 |
SAE 5W-20, API Latest (ILSAC Latest) *5, *8 |
|
|
For Middle East, India*3 |
SAE 5W-30, ACEA A5/B5 *4 *5 |
|||
|
Manual transmission fluid |
HK SYN MTF 70W (SK) SPIRAX S6 GHME 70W MTF (H.K.SHELL) GS MTF HD 70W (GS CALTEX) (API GL-4, SAE 70W, TGO-9) |
|||
|
Smartstream G1.6 |
1.5~1.6 ℓ (1.6~1.7 US qt.) |
|||
|
1.6 D-CVVT |
1.5~1.6 ℓ (1.6~1.7 US qt.) |
|||
|
Automatic transmission fluid |
7.5 ℓ (7.9 US qt.) |
SK ATF SP4M-1, MICHANG ATF SP4M-1, S-OIL ATF SP4M-1, Hyundai Genuine ATF SP4M-1 |
||
|
Intelligent variable transmission fluid |
6.5 ℓ (6.87 US qt.) |
Hyundai genuine SP-CVT1 |
||
|
Dual clutch transmission fluid |
1.6~1.7 ℓ (1.7~1.8 US qt.) |
SAE 70W, API GL-4, HK D DCTF TGO-10 PLUS (SK) SPIRAX S6 GHDE 70W DCTF PLUS (H.K.SHELL) |
||
|
Coolant |
Smartstream G2.0 |
7.4 ℓ (7.82 US qt.) |
Mixture of antifreeze and water (Phosphate-based Ethylene glycol coolant for aluminum radiator) |
|
|
Smartstream G1.6 |
6.1 ℓ (6.45 US qt.) |
|||
|
Smartstream G1.6 T-GDI |
6.8 ℓ (7.19 US qt.) |
|||
|
1.6 D-CVVT |
7.1 ℓ (7.5 US qt.) |
|||
|
Brake/clutch fluid |
0.7~0.8 ℓ (0.74~0.85 US qt.) |
DOT-4*6 |
||
|
Fuel |
47 ℓ (49.66 US qt.) |
Refer to “Fuel requirements” in the Foreword chapter. |
||
If the above recommended specification oil is not available, SAE 0W-20 grade synthetic oil can be used. If mineral oil or semi-synthetic oil is used, it is a severe maintenance condition in terms of engine oil change.
Requires <API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition.
Middle East includes Libya, Algeria, Morocco, Egypt, Tunisia, Sudan, Iran, etc.
Requires <API Latest(ILSAC Latest) or ACEA A5/B5 Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, the engine oil and engine oil filter must be replaced according to the indicated severe maintenance condition.
Refer to the Recommended SAE viscosity numberon page 14.
To maintain the best braking performance and ABS/ESC performance, we recommend that you use genuine brake fluid that conform to specifications. (Standard : SAE J1704 DOT-4 LV, ISO4925 CLASS-6 and FMVSS116 DOT-4)
Requires <API SN PLUS (or above) or ACEA A5/B5 Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition.
Requires <API Latest(ILSAC Latest) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, the engine oil and engine oil filter must be replaced according to the indicated severe maintenance condition.
