This warning light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 6 seconds and then goes off.

• When there is a malfunction with the SRS.

• In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This warning light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 3 seconds

  • It remains on if the parking brake is applied.

• When the parking brake is applied.

• When the brake fluid level in the reservoir is low.

  • If the warning light illuminates with the parking brake released, it indicates the brake fluid level in the reservoir is low.

If the brake fluid level in the reservoir is low:

1. Drive carefully to the nearest safe location and stop your vehicle.

2. With the engine stopped, check the brake fluid level immediately and add fluid as required (For more details, refer to “Brake/clutch fluid” in chapter 9). After adding brake fluid, check all brake components for fluid leaks. If a brake fluid leak is found, or if the warning light remains on, or if the brakes do not operate properly, do not drive the vehicle. We recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

Dual-diagonal braking system

Your vehicle is equipped with dual-diagonal braking systems. This means you still have braking on two wheels even if one of the dual systems should fail.

With only one of the dual systems working, more than normal pedal travel and greater pedal pressure are required to stop the vehicle.

Also, the vehicle will not stop in as short a distance with only a portion of the brake system working.

If the brakes fail while you are driving, shift to a lower gear for additional engine braking and stop the vehicle as soon as it is safe to do so.

This warning light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When there is a malfunction with the ABS (The normal braking system will still be operational without the assistance of the anti-lock brake system).

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

These two warning lights illuminate at the same time while driving:

• When the ABS and regular brake system may not work normally.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This warning light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When there is a malfunction with the EPB.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This indicator light illuminates:

• White: When you activate the auto hold system by pressing the AUTO HOLD button.

• Green: When you stop the vehicle completely by depressing the brake pedal with the auto hold system activated.

• Yellow: When there is a malfunction with the auto hold system.

• In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

For more details, refer to “Auto Hold” in chapter 6.

This warning light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When there is a malfunction with the MDPS.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This warning light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When there is a malfunction with the emission control system.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This warning light illuminates:

• When you set the ignition switch to the ON position.

  • The Forward Safety warning light illuminates for approximately 3 seconds and then goes off.

• Continuously Yellow: When Forward safety of Forward Collision-Avoidance Assist is Deselected/Disabled/Malfunction.

The indicator light blinks:

• Red: When Forward safety of Forward Collision-Avoidance Assist is operating.

If this occurs, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible.

For more details, refer to “Forward Collision-Avoidance Assist (FCA) (front view camera only)” in chapter 7.

This indicator light illuminates:

• Green: When Lane Keeping Assist operating conditions are satisfied.

• Grey: When Lane Keeping Assist operating conditions are not satisfied.

• Yellow: Whenever there is Deselected/Disabled/Malfunction with Lane Keeping Assist.

If the yellow warning light remains on after the sensor has been uncovered or unblocked when Lane Safety is set, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer.

The indicator light blinks:

• Green: When Lane Keeping Assist is operating.

For more details, refer to "Lane Keeping Assist (LKA)" in chapter 7.

This indicator light illuminates:

• When you set the ignition switch or Engine Start/Stop button to the ON position.

• Yellow: When Driver Attention Warning is disabled or a malfunction is detected

If the yellow indicator light remains on after the front view camera has been uncovered or unblocked, we recommend that your vehicle be inspected by an authorized HYUNDAI dealer.

This indicator light blinks:

• Yellow: Driver Attention Warning recommends to take a break

For more details, refer to “Driver Attention Warning (DAW)” in chapter 7.

This warning light illuminates:

• When there is a malfunction with either the alternator or electrical charging system

If there is a malfunction with either the alternator or electrical charging system:

1. Drive carefully to the nearest safe location and stop your vehicle.

2. Turn the engine off and check the alternator drive belt for looseness or breakage.

   If the belt is adjusted properly, there may be a problem in the electrical charging system.

   In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible.

This warning light illuminates:

• When the engine oil pressure is low.

If the engine oil pressure is low:

1. Drive carefully to the nearest safe location and stop your vehicle.

2. Turn the engine off and check the engine oil level (For more details, refer to “Engine oil” in chapter 9). If the level is low, add oil as required.

   If the warning light remains on after adding oil or if oil is not available, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible.

   Continued driving with the warning light on may cause engine failure.

This warning light illuminates:

• When the fuel tank is nearly empty. Add fuel as soon as possible.

This warning light blinks:

• When you drive the vehicle more than 120 km/h.

  • This is to prevent you from driving your vehicle with overspeed.

  • The overspeed warning chime also sound for approximately 5 seconds.

This warning light illuminates:

• When there is a malfunction in operation in any of the following systems:

  • Forward Collision-Avoidance Assist malfunction (if equipped)

  • Blind-Spot Collision-Avoidance Assist malfunction (if equipped)

  • Blind-Spot Collision-Avoidance Assist radar blocked (if equipped)

  • Smart Cruise Control malfunction (if equipped)

  • Smart Cruise Control radar blocked (if equipped)

  • LED head light malfunction (if equipped)

  • High Beam Assist malfunction (if equipped)

To identify the details of the warning, look at the instrument cluster.

This warning light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When one or more of your tires are significantly underinflated (The location of the underinflated tires are displayed on the cluster display).

This warning light remains on after blinking for approximately 60 seconds or repeatedly blinks on and off at approximately 3 second intervals:

• When there is a malfunction with the TPMS.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible.

This indicator light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When there is a malfunction with the ESC system.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This indicator light blinks:

• While the ESC is operating.

For more details, refer to “Electronic Stability Control (ESC)” in chapter 6.

This indicator light illuminates:

• When you set the ignition switch to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When you deactivate the ESC system by pressing the ESC OFF button.

For more details, refer to “Electronic Stability Control (ESC)” in chapter 6.

This indicator light illuminates:

• When the vehicle detects the immobilizer in the key with the ignition switch in the ON position.

  • At this time, you can start the engine.

  • The indicator light goes off after starting the engine.

This indicator light blinks:

• When there is a malfunction with the immobilizer system.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This indicator light illuminates for up to 30 seconds:

• When the vehicle detects the smart key in the vehicle with the Engine Start/Stop button in the ACC or ON position.

  • At this time, you can start the engine.

  • The indicator light goes off after starting the engine.

This indicator light blinks for a few seconds:

• When the smart key is not in the vehicle.

  • At this time, you cannot start the engine

This indicator light illuminates for 2 seconds and goes off:

• If the smart key is in the vehicle and the Engine Start/Stop button is ON, but the vehicle cannot detect the smart key.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This indicator light blinks:

• When there is a malfunction with the immobilizer system.

  In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.

This indicator light blinks:

• When you operate the turn signals.

  If any of the following occur, there may be a malfunction with the turn signal system.

  • The turn signal indicator light illuminates but does not blink

  • The turn signal indicator light blinks rapidly

  • The turn signal indicator light does not illuminate at all

If any of these conditions occur, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer.

This indicator light illuminates:

• When the headlights are on.

This indicator light illuminates:

• When the headlights are on and in the high beam position.

• When the turn signal lever is pulled into the Flash-to-Pass position.

This indicator light illuminates:

When the high-beam is on with the light switch in the AUTO light position.

• White: When High Beam Assist is ready to operate.

• Green: When High Beam Assist is operating.

If your vehicle detects oncoming or preceding vehicles, High Beam Assist will switch the high beam to low beam automatically.

For more details, refer to “High Beam Assist (HBA)” in chapter 5.

This warning light illuminates:

• When one of the exterior bulbs (headlight, DRL, turn signal light, stop light, etc) is not operating properly. One of the bulbs may need to be replaced.

This warning light illuminates:

• When you set the Engine Start/Stop button to the ON position.

  • The LED headlight warning light illuminates for approximately 3 seconds and then goes off.

• Whenever there is a malfunction with the LED headlight.

If this occurs, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer.

This indicator light illuminates:

• When the tail lights or headlights are on.

This indicator light illuminates:

• When the rear fog lights are on.

This indicator light illuminates:

• When the cruise control system is enabled.

For more details, refer to “Cruise Control (CC)” in chapter 7.

This indicator light illuminates:

• When you select “SPORT” mode as drive mode.

For more details, refer to “Drive mode integrated control system (2WD)” in chapter 6.

This indicator light illuminates:

• When you select “ECO” mode as drive mode.

For more details, refer to “Drive mode integrated control system (2WD)” in chapter 6.

This indicator light illuminates:

• When you select ‘’SMART” mode as drive mode.

For more details, refer to “Drive mode integrated control system (2WD)’’ in chapter 6.

This indicator light illuminates:

This warning light is to warn the driver the road may be icy.

When the temperature on the outside temperature gauge is approximately below 4°C (40°F), the Icy Road Warning Light and Outside Temperature Gauge blinks and then illuminates. Also, the warning chime sounds 1 time.

The Icy Road Warning function can be activated or deactivated from the User Settings mode in the instrument cluster.
