Recommended Lubricants and Capacities
To help achieve proper engine and power train performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
|
Lubricant |
Volume |
Classification |
|
|
Engine oil *1*2 Recommends
|
6.86 US qt. (6.5 ℓ) |
ACEA A5 or above *3 / 5W-30 / (SAE Viscosity Number) |
|
|
Automatic transmission fluid |
7.39 US qt. (7.0 ℓ) |
SK ATF SP4M-1, MICHANG ATF SP4M-1, S-OIL ATF SP4M-1, Hyundai Genuine ATF SP4M-1 or other brands meeting the above specification approved by HYUNDAI Motor Co. |
|
|
Engine coolant |
Without trailer |
12.44 US qt. (11.79 ℓ) |
Mixture of antifreeze and water (Phosphate-based Ethylene glycol coolant for aluminum radiator) |
|
With trailer |
12.65 US qt. (11.98 ℓ) |
||
|
Brake fluid *4 |
As required |
SAE J1704 DOT-4LV, FMVSS116 DOT-4, ISO4925 CLASS-6 |
|
|
Rear differential oil *5 |
0.73 US qt. (0.7 ℓ) |
HYPIO GEAR OIL API GL-5, SAE 75W/85 (SK HCT-5 GEAR OIL 75W/85 or EQUIVALENT) |
|
|
Transfer case oil (AWD) *5 |
0.73 US qt. (0.7 ℓ) |
||
|
Fuel |
18.75 US gal. (71 ℓ) |
Refer to “Fuel Requirements” in chapter 1. |
|
Refer to the recommended SAE viscosity numbers on the next page.
Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel economy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year’s time, they can offer significant cost and energy savings.
Requires <API Latest (or ILSAC Latest) or ACEA A5/B5 Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated for severe maintenance conditions.
To maintain the best braking performance and ABS/ESC performance, we recommend that you use genuine brake fluid that conform to specifications.
If the rear differential is submerged, have you visit an authorized retailer of HYUNDAI genuine products to replace the differential oil.
