Recommended lubricants and capacities
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
|
Lubricant |
Volume |
Classification |
|||
|
Engine oil *1 (drain and refill)
|
Gasoline Engine |
Smartstream G2.5 GDi |
5.8 ℓ (6.13 US qt.) |
SAE 0W-20, API SN PLUS/SP or ILSAC GF-6*2 |
|
|
Smartstream G2.0 |
4.3 ℓ (4.54 US qt.) |
SAE 0W-20, API SN PLUS/SP or ILSAC GF-6*2 |
|||
|
Smartstream G1.6 T-GDi |
4.8 ℓ (5.07 US qt.) |
SAE 0W-20, API SN PLUS/SP or ILSAC GF-6*2 |
|||
|
Diesel Engine |
Smartstream D2.0 |
With DPF*3 |
5.6 ℓ (5.92 US qt.) |
ACEA C5, ACEA C3, ACEA C2 |
|
|
Without DPF*3 |
ACEA A3/B4 |
||||
Refer to the Recommended SAE viscosity number.
Requires <API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition
DPF: Diesel Particulate Filter
|
Lubricant |
Volume |
Classification |
|||||
|
Automatic transmission fluid |
Gasoline Engine |
Smartstream G2.0 |
2WD |
6.7 ℓ (7.08 US qt.) |
SK ATF SP4M-1, MICHANG ATF SP4M-1, S-OIL ATF SP4M-1, HYUNDAI Genuine ATF SP4M-1 |
||
|
4WD |
|||||||
|
Smartstream G2.5 GDi |
2WD |
6.5 ℓ (6.87 US qt.) |
|||||
|
4WD (N-line) |
|||||||
|
Diesel Engine |
Smartstream D2.0 |
2WD |
7.0 ℓ (7.4 US qt.) |
||||
|
4WD |
|||||||
|
4WD (N-line) |
|||||||
|
Manual transmission fluid |
Smartstream G2.0 |
2WD |
1.5-1.6 ℓ (1.58-1.69 US qt.) |
API GL-4, SAE 70W - SK : HK SYN MTF 70W - H.K.SHELL : SPIRAX S6 GHME 70W MTF - GS CALTEX : GS MTF HD 70W |
|||
|
4WD |
1.4-1.5 ℓ (1.48-1.59 US qt.) |
||||||
|
Dual clutch transmission fluid |
Smartstream G1.6 T-GDi |
2WD |
1.6-1.7 ℓ (1.69-1.80 US qt.) |
API GL-4, SAE 70W - SK: HK D DCTF TGO-10 PLUS - H.K.SHELL : SPIRAX S6 GHDE 70W DCTF PLUS |
|||
|
4WD |
|||||||
|
Brake fluid*1 |
LHD*5 |
0.82 ± 0.02 ℓ (0.87 ± 0.02 US qt.) |
SAE J1704 DOT-4 LV, ISO4925 CLASS-6, FMVSS 116 DOT-4 |
||||
|
RHD*6 |
0.79 ± 0.02 ℓ (0.83 ± 0.02 US qt.) |
||||||
|
Rear differential oil (4WD) |
0.53-0.63 ℓ (0.56-0.67 US qt.) |
HYPOID GEAR OIL API GL-5, SAE 75W/85 (SK HCT-5 GEAR OIL 75W/85 or EQUIVALENT) |
|||||
|
Transfer case oil (4WD) |
DCT*2 |
0.48-0.52 ℓ (0.50-0.54 US qt.) |
|||||
|
M/T*4 |
|||||||
|
A/T*3 |
0.62-0.68 ℓ (0.65-0.71 US qt.) |
||||||
|
Fuel |
54 ℓ (14.26 US gal.) |
Refer to "Fuel requirements" in chapter 1. |
|||||
|
Urea solution (Diesel Engine) |
14 ℓ (14.79 US qt.) |
ISO22241, DIN70070 |
|||||
|
Coolant |
Smartstream G2.0 |
M/T*4 |
2WD |
6.4 ℓ (6.76 US qt.) |
MIXTURE, Antifreeze with water (Ethylene glycol base coolant for aluminum radiator) |
||
|
4WD |
|||||||
|
A/T*3 |
2WD |
6.4 ℓ (6.76 US qt.) |
|||||
|
4WD |
|||||||
|
Smartstream G1.6 T-GDi |
DCT*2 |
2WD |
7.2 ℓ (7.61 US qt.) |
||||
|
4WD |
|||||||
|
Smartstream G2.5 GDi |
A/T*3 |
2WD |
8.4 ℓ (8.88 US qt.) |
||||
|
4WD |
|||||||
|
Smartstream D2.0 |
A/T*3 |
2WD |
8.4 ℓ (8.88 US qt.) |
||||
|
4WD |
|||||||
The amount of oil required may vary depending on the brake air bleeding method.
DCT : Dual clutch transmission
A/T : Automatic transmission
M/T : Manual transmission
LHD : Left-hand drive type
RHD : Right-hand drive type
