Recommended lubricants and capacities
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
|
Lubricant |
Volume |
Classification |
||
|
Engine oil *1 *2 Recommends
|
Smartstream G3.5 |
Except Middle East, Livia, Algeria, Iran, Morocco, Sudan, Tunisia, Egypt, India |
6.1 ℓ (6.4 US qt.) |
SAE 0W-20, API SN PLUS/SP or ILSAC GF-6 *3 |
|
For Middle East, Livia, Algeria, Iran, Morocco, Sudan, Tunisia, Egypt, India |
SAE 5W-30, ACEA A5/B5 *4 |
|||
|
(Diesel) 2.2 VGT |
6.5 ℓ (6.8 US qt.) |
ACEA C5 (or C3 or C2) SAE: 0W-30 |
||
|
Urea solution (Diesel engine) |
14 ℓ (15 US qt.) |
ISO 22241 or DIN 70070 |
||
|
Automatic transmission fluid |
Smartstream G3.5 |
7.0 ℓ (7.4 US qt.) |
SK ATF SP4M-1, MICHANG ATF SP4M-1, S-OIL ATF SP4M-1, Hyundai Genuine ATF SP4M-1 |
|
|
(Diesel) 2.2 VGT |
7.1 ℓ (7.5 US qt.) |
|||
|
Manual transmission fluid |
(Diesel) 2.2 VGT |
1.8~1.9ℓ (1.9~2.0 US qt.) |
HK SYN MTF 70W (SK)SPIRAX S6 GHME 70WMTF (H.K.SHELL)GS MTF HD 70W (GS CALTEX) API GL-4, SAE 70W, TGO-9 |
|
|
Engine coolant |
Smartstream G3.5 |
9.3 ℓ (9.8 US qt.) |
Mixture of antifreeze and water (Phosphate-based Ethylene glycol coolant for aluminum radiator) |
|
|
(Diesel) 2.2 VGT |
9.6 ℓ (10.1 US qt.) |
|||
|
Brake/clutch (if equipped) fluid *5 |
As required |
SAE J1704 DOT-4LV, FMVSS116 DOT-4, ISO4925 CLASS-6 |
||
|
Rear differential oil *6 |
0.65 ± 0.05 ℓ (0.69 ± 0.05 US qt.) |
HYPOID GEAR OIL API GL-5, SAE 75W85 (SK HCT-5 GEAR OIL 75W85 OR EQUIVALENT) |
||
|
Transfer case oil (4WD) |
0.70 ± 0.03 ℓ (0.74 ± 0.03 US qt.) |
HYPOID GEAR OIL API GL-5, SAE 75W85(SK HCT-5 GEAR OIL 75W85 OR EQUIVALENT) |
||
|
Fuel |
75 ℓ (19.8 US gal.) |
Refer to "Fuel requirements" in chapter 1. |
||
Refer to the recommended SAE viscosity numbers on the next page.
Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel economy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year's time, they can offer significant cost and energy savings.
Requires < API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition.
Requires <API SN PLUS (or above) or ACEA A5/B5 Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition.
To maintain the best braking performance and ABS/ESC performance, we recommend that you use genuine brake fluid that conform to specifications.
: If the front/rear differential is submerged, we recommend that you visit an authorized HYUNDAI dealer to replace the differential oil.
* Middle East includes Livia, Algeria, Iran, Morocco, Sudan, Tunisia, Egypt and India
