Recommended Lubricants and Capacities
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote the engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
|
Lubricant |
Volume |
Classification |
|
|
Engine oil *1*2 (drain and refill) Recommends
|
6.13 US qt. (5.8 ℓ) |
SAE 0W-20 API SN PLUS/SP or ILSAC GF-6*3 |
|
|
Automatic transmission fluid |
7.39 US qt. (7.0 ℓ) |
SK ATF SP4M-1, MICHANG ATF SP4M-1, S-OIL ATF SP4M-1 or other brands meeting the above specification approved by HYUNDAI Motor Co. |
|
|
Coolant |
12.44 US qt. (11.77 ℓ) |
MIXTURE, Antifreeze with water (Ethylene glycol base coolant for aluminum radiator) |
|
|
Brake fluid *4 |
As required |
DOT-4 |
|
|
Rear differential oil (4WD) *5 |
0.67 US qt. (0.65 ℓ) |
HYPOID GEAR OIL API GL-5, SAE 75W/85 (SK HCT-5 GEAR OIL 75W/85 or EQUIVALENT) |
|
|
Transfer case oil (4WD) *5 |
0.74 US qt. (0.7 ℓ) |
||
|
Electronic Limited Differential (e-LSD) oil |
0.507 ± 0.015 US qt. (480 ± 15 mℓ) |
SHELL TF0870C or equivalent |
|
|
Fuel |
19 US gal. (72ℓ) |
Refer to Fuel Requirements. Refer to 'Fuel Requirements' section in chapter 10 of the complete Owner's Manual. |
|
Refer to Recommended SAE viscosity number.
Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel economy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year's time, they can offer significant cost and energy savings.
Requires <API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition.
To maintain the best braking performance and ABS/ESC performance, use genuine brake fluid that conform to specifications. (SAE J1704 DOT-4 LV, FMVSS 116 DOT-4, ISO4925 CLASS-6)
If the transfer case/rear differential is submerged, visit an authorized HYUNDAI genuine products to replace the differential oil.
Severe engine and transmission damage may result from the use of poor quality fuels and lubricants that do not meet HYUNDAI specifications. Always use high quality fuels and lubricants that meet the specifications listed in the recommended table.
Engine oil viscosity (thickness) has an effect on fuel economy and cold weather operating (engine start and engine oil flowability). Lower viscosity engine oils can provide better fuel economy and cold weather performance, however, higher viscosity engine oils are required for satisfactory lubrication in hot weather. Using oils of any viscosity other than those recommended may result in engine damage.
When choosing an oil, consider the range of temperature your vehicle is operated in before the next oil change.
|
Temperature Range for SAE Viscosity Numbers |
||
|
Temperature |
°C |
|
|
(°F) |
||
|
Smartstream G3.5 GDI |
|
|
-
Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaning the plug and dipstick areas will prevent dirt and grit from entering the engine and other mechanisms that could be damaged.
-
Never add any additives to the engine oil. Engine oil additives can change the properties of engine oil and may cause serious engine failure.
An engine oil displaying this API Certification Mark conforms to the international Lubricant Specification Advisory Committee (ILSAC). It is recommended to only use engine oils that uphold this API Certification Mark.
